aluminum window

Good quality China factory price Aluminum Profiles extrude+ raw material/anodize/powder coating+fabrication

Which Aluminium Profiles We could supply

• Alloy:1060,2024,3003,5005,5056,6063, 6061, 6082, 6060, 6005, 6A02


• Temp:T1, T4, T5, T6


• Finish:Mill finish, Anodized,Powder coated,Electrophoresis,Wooden grain.


• Extrude size:10mm-250mm

Technology Supports

• Engineering design


• Autocad drawing


• Aluminium profiles deeply processing:cutting,punching,drilling,milling,dending and fabricating.


•


  --Yous any inquire will get a prompt reply with 12hours from our skilled sales.


















































































































































































































  1.General Chemical Composition of the aluminum tube
  Aluminum Grade	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	impurity	Al
  6063	0.2-0.6	<0.35	<0.1	<0.1	0.45-0.9	<0.1	<0.1	<0.1	<0.15	Rest
  6061	0.4-0.8	0.7	0.15-0.4	<0.15	0.8-1.2	0.04-0.35	<0.25	<0.15	<0.15	Rest
  2.Mechanical Properties of Sections under Room Temperature
  Aluminum Grade	Temper	Wall Thickness	Resist Pull Point(Mpa)	Stretch (Rpo.2 Mpa)	Stretch Rate	Webster  Hardness
  6063	T5	All	160	110	8	8
  	T6	All	205	180	8
  6061	T4	All	180	110	16
  	T6	All	265	245	8
  3.SurfaceTreatment of Sections
  (Class)	(μm),not diminish than		acid-resistant			abrasion resistance
  	(Min-average film  thickness)	(Min-part film  thickness)	CASS		(S)	(f, g /μm)
  			(h)	Class
  AA10	10	8	16	≥9	≥50	≥300
  AA15	15	12	32	≥9	≥75	≥300
  AA20	20	16	56	≥9	≥100	≥300
  AA25	25	20	72	≥9	≥125	≥300









   Introduce us




           we are the only one  supplier of aluminum profile to the China Beijing Olympic game 2008 such as the national stadium (the birds nest) and the National Aquatics. We have 300000 tons capacity a year. And fully fabriceted windows and doors as well.




  Facilities30: Production Lines, 78 Sets Of Production Machines With Full Sets Of Inspection Facilities.




  Alloy Property and Temper:     A Broad Range of Alloy(e.g.,6063,6061,6082,6005,6060.6101,6463)




  Finishes Alternatives:





  • Anodized and Electrophoresis Deposition


  • Powder Coated:Liquid supplier AKZO NOBEL


  • Liquid Coated: A broad range of paints (e.g.,PVDF/fluoropolymers, polyesters, acrylics, and siliconized polyesters) Liquid supplier PPG


  • Mechanical finishes: Sanded,Polished,Grinded,Buffing,Blasted





  Export Experience:10 Years All Over The World.










  1. Five 15-Tons Hot Top Refining Stoves.


  2. Maximum Billet Diameter: ¢320mm





  Extrusion System










  • Shapes: Various Shapes. In Agreement With Design Draings Or Samples.


  • Maximum Cross Section Width And Cut Length: 410mm And 13mm.


  • Presses And Tonnage: 30 Extrusion Machines Imported From Taiwan And Europe, 600 To 4000 Us Tons.


  • Production Capacity:300,000 Tons Per Year.


  • Standardization :EN755,EN12020,ASTM B221,ANSIH35.2





  Powder Coating System:





  • Colors: Various. Ral colors. In agreement with samples.


  • Liquid Suppliers:AKZO NOBEL and ORICA.


  • Durability and Weathering:10 Years.


  • Standardization: QUALICOAT, EN12206,AAMA 2603,AAMA 2604, BS6496, GB5237.4-2004


  •





  Fluorocarbon Coating System




          Facilities: One Vertical Coating Production Lines Made In Switzerland, Sprayer Made In Japan.





  • Colors: Various. Ral colors. In agreement with samples.


  • Liquid Suppliers:PPG


  • Durability and Weathering:15 Years.


  • Standardization: QUALICOAT, AAMA 2603,AAMA 2605, GB5237.4-2004


  •





  Anodizing System





  • Facilities: Six Anodizing Production Lines Made In Taiwan.


  • Colors: Silver, Champaign,Bronze,Black, Stainless,Gold,Platinum,etc.


  • Maximun Film Thickness:35um


  • Standardization: QUALANOD,EN12373, ..


  •





  Self-Running Mould Factory




  Production Capacity:50,000 Sets Per Year




  CAD/CAM Mould Design Aviable









   Facilities:CNC Machine(Elumatec,Germany),Saw,Punchers,Driller,Miller,Copy Router, Profile Machining Centres,Corner Crimpers,Assembly Equipment,Etc
